产品型号 | 频率 (MHz) |
输出类型 | 频率稳定度 (ppb) |
供电电压 (V) |
工作温度范围 (°C) |
封装尺寸 长 x 宽 x 高 (mm) |
产品类别 | 规格书 | 产品图片 |
ETOCXO3526C | 8 to 30 | HCMOS, Sinewave | 10 | 3.3, 5 | -40 to +125 | 35.4 x 26.7 x 10.5 | Extended Temperature | ||
ETOCXO2020C | 8 to 30 | HCMOS, Sinewave | 10 | 3.3, 5 | -40 to +125 | 20.2 x 20.2 x 10.3 | Extended Temperature | ||
ETOCXO2525C | 8 to 30 | HCMOS, Sinewave | 10 | 3.3, 5 | -40 to +125 | 25.8 x 25.8 x 10.7 | Extended Temperature | ||
OCXO3307C-ET | 8 to 150 | Sinewave | 20 | 3.3, 5 | -60 to +85 | 21.6 x 15.3 x 9.5 | Extended Temperature | ||
OCXO3306C | 8 to 120 | HCMOS | 50 | 3.3, 5 | -30 to +70 | 20.5 x 15.1 x 8.0 | Low Power | ||
OCXO3312C | 8 to 150 | HCMOS, TTL, Sinewave | 5 | 3.3, 5 | -40 to +85 | 15.9 x 15.1 x 8.8 | Low Power | ||
OCXO3313C | 8 to 150 | HCMOS | 5 | 3.3, 5 | -40 to +85 | 15.9 x 15.1 x 8.8 | Low Power | ||
OCXO3307C | 8 to 150 | HCMOS | 3 | 3.3, 5 | -40 to +85 | 20.5 x 15.1 x 8.8 | Low Power | ||
OCXO3308C | 8 to 150 | HCMOS, Sinewave | 3 | 3.3, 5 | -40 to +85 | 21.51 x 15.1 x 8.8 SMD | Low Power | ||
OCXO3311C | 8 to 100 | HCMOS | 50 | 3.3, 5 | -30 to +70 | 15.9 x 15.1 x 10.0 | Low Power | ||
OCXO3315C | 8 to 100 | HCMOS, TTL, Sinewave | 5 | 3.3, 5 | -40 to +85 | 20.5 x 15.3 x 10.5 | Low Power | ||
OCXO3316C | 30 to 300 | HCMOS | 5 | 3.3, 5 | -55 to +85 | 21.8 x 15.0 x 10.0 | Low Power | ||
OCXO2522C | 5 to 150 | HCMOS, TTL, Sinewave | 10 | 3.3, 5, 12 | -40 to +85 | 25.4 x 22 x 11 | High Stability | ||
DOCXO2020C | 5 to 100 | HCMOS, TTL, Sinewave | 0.1 | 3.3, 5, 12 | -40 to +80 | 20.2 x 20.2 x 12.6 | High Stability | ||
DOCXO3627C | 5 to 100 | HCMOS, TTL, Sinewave | 0.1 | 3.3, 5, 12 | -40 to +85 | 35.4 x 26.7 x 16.25 | High Stability | ||
OCXO2525S | 10 | LVTTL | 3 | 5 | -40 to +85 | 25.4 x 25.4 x 12.7 DIP | Standard | ||
OCXO3627S | 10 | LVTTL | 3 | 12 | -40 to +85 | 36.3 x 27.2 x 12.7 | Standard | ||
OCXO2020S | 10 | HCMOS | 5 | 3.3, 5 | -40 to +85 | 20.6 x 20.6 x 11.0 DIP | Standard | ||
OCXO2522S | 10 | HCMOS | 5 | 3.3, 5 | -40 to +85 | 25.4 x 22.1 x 11.0 SMD | Standard | ||
OCXO3306 | 10 | Sinewave | 0.5 | 4.2 | -40 to +65 | 20.2 x 20.2 x 14.1 | High Stability | ||
OCXO2828LULN1 | 5 to 150 | Sinewave | 5 | 5 | -40 to +85 | 27.8 x 27.8 x 15.5 | High Performance | ||
OCXO2828LULN2 | 5 to 150 | Sinewave | 5 | 12 | -40 to +85 | 27.8 x 27.8 x 15.5 | High Stability | ||
OCXO2013ZS1 | 10 to 60 | Sinewave | 200 | 3.3 | -40 to +85 | 20.8 x 13.2 x 7.8 | Standard | ||
OCXO2013ZS2 | 10 to 60 | Sinewave | 200 | 5 | -40 to +85 | 20.8 x 13.2 x 7.8 | Standard | ||
OCXO3627C | 5 to 150 | HCMOS, TTL, Sinewave | 10 | 3.3, 5, 12 | -40 to +85 | 35.4 x 26.7 x 12 | High Stability | ||
OCXO2525C | 5 to 150 | HCMOS, TTL, Sinewave | 10 | 3.3, 5, 12 | -40 to +85 | 25.8x25.8x12.7 | High Stability | ||
OCXO2020C | 5 to 150 | HCMOS, TTL, Sinewave | 10 | 3.3, 5, 12 | -40 to +85 | 20.2x20.2x12 | High Stability | ||
OCXO2526S-100MHz | 100 | Sinewave | 50 | 5 | -40 to +85 | 25 x 25 x 12 | Low Noise | ||
DOCXO3627S-10MHz | 10 | HCMOS | 0.5 | 3.3 | -30 to +70 | 36 x 27 x 18 | Double Oven Controlled | ||
OCXO1490S | 5 to 40 | HCMOS | 30 | 3.3, 5 | -40 to +85 | 14.3 x 9.3 x 6.5 | Standard | ||
DOCXO3628S-10MHz | 10 | HCMOS | 0.5 | 5 | -30 to +70 | 36 x 27 x 18 | Double Oven Controlled | ||
OCXO9700S | 10 to 40 | Rectangular, Clipped Sinewave | 20 | 3.3, 5 | -40 to +85 | 9.7 x 7.5 x 4.1 | Standard | ||
OCXO2021C | 30 to 300 | HCMOS, TTL, Sinewave | 5 | 3.3, 5, 12 | -60 to +85 | 20 x 20 x 13 | High Stability | ||
OCXO3629C | 30 to 300 | HCMOS, TTL, Sinewave | 5 | 3.3, 5, 12 | -60 to +85 | 35.4 x 26.7 x 12 | High Stability | ||
OCXO2523C | 30 to 300 | HCMOS, TTL, Sinewave | 5 | 3.3, 5, 12 | -60 to +85 | 25.4 x 22 x 11 | High Stability | ||
OCXO2526C | 30 to 300 | HCMOS, TTL, Sinewave | 5 | 3.3, 5, 12 | -60 to +85 | 25.8 x 25.8 x 12.7 | High Stability | ||
OCXO3628S-100MHz | 100 | Sinewave | 50 | 5 | -20 to +70 | 36 x 27 x 16 | Low G-Sensitivity | ||
OCXO2525S-100MHz-ULN-X | 100 | Sinewave | 50 | 12 | -40 to +85 | 25.8 x 25.8 x 12.7 | Low Phase-noise | ||
OCXO2525S-10MHz-A-V | 10 | Sinewave | 20 | 12 | -40 to +85 | 25.78 x 25.78 x 14 | Ultra Low Noise | ||
OCXO2525AR-122.88MHz-A-V | 122.88 | Sinewave | 100 | 12 | -30 to +70 | 25.8 x 25.8 x 12 | High Stability | ||
OCXO2525AW-12.8MHz-A-V | 12.8 | HCMOS | 1 | 5 | 0 to +70 | 25.8 x 25.8 x 13.5 | High Stability | ||
OCXO3317AW | 8 to 100 | HCMOS, Sinewave | 10 | 3.3, 5 | -40 to +85 | 16.0 x 15.0 x 10.5 | High Stability | ||
OCXO5050AN-61.44MHz-A-V | 61.44 | Sinewave | 100 | 12 | -40 to +70 | 50.8 x 50.8 x 12.7 | Low Phase Noise | ||
OCXO3318AW | 8 to 150 | HCMOS, TTL, Sinewave | 5 | 3.3, 5 | -40 to +85 | 16 x 15.3 x 11.6 | Low Power | ||
OCXO5050AN-60MHz-A-V | 60 | Sinewave | 50 | 12 | 0 to +50 | 50.8 x 50.8 x 12.7 | Low Phase Noise | ||
DOCXO5050AN-10MHz | 10 | Sinewave | 0.1 | 5, 12 | -40 to +85 | 51 x 51 x 19 | High Stability | ||
OCXO5151AN-10MHz | 10 | Sinewave | 5 | 12 | -40 to +80 | 50.8 x 50.8 x 16 | Low Phase Noise | ||
OCXO2525ANLG-10MHz | 10 | Sinewave | 10 | 5, 12 | -40 to +85 | 25.8 x 25.8 x 12.7 | Low Phase Noise | ||
OCXO3309AW-40MHz-A-V | 40 | HCMOS | 100 | 3.3 | -40 to +85 | 16 x 15.3 x 9.5 | Low Power | ||
OCXO3319AW | 30 to 300 | Sinewave | 5 | 3.3, 5 | -60 to +85 | 20.5 x 12.7 x 9.5 | High Stability | ||
OCXO3319AW | 30 to 300 | Sinewave | 5 | 3.3, 5 | -60 to +85 | 20.5 x 12.7 x 9.5 | High Stability | ||
OCXO2525AN-200MHz-A-V | 200 | Sinewave | 100 | 12 | -40 to +70 | 25.8 x 25.8 x 10.3 | High Stability | ||
OCXO3312AW-12.288MHz-A-V | 12.288 | HCMOS | 10 | 5 | -40 to +85 | 16 x 15 x 9.5 | Low Power | ||
OCXO3312AW-16.384MHz-A-V | 16.384 | HCMOS | 10 | 5 | -40 to +85 | 16 x 15 x 9.5 | Low Power | ||
OCXO5152AN-10MHz-A-V | 10 | Sinewave | 0.5 | 5 | 0 to +50 | 50.8 x 50.8 x 12.7 | High Stability | ||
DOCXO5051AN-10MHz-A-V | 10 | Sinewave | 0.1 | 5 | 0 to +50 | 49 x 49 x 19 | High Stability | ||
DOCXO3627C-51422-30MHz | 30 | Sinewave | 0.05 | 12 | -30 to +70 | 35.4 x 26.7 x 15.8 | High Stability | ||
OCXO2526AXLN-100MHz-A-V | 100 | Sinewave | 50 | 3.3 | -40 to +85 | 25.4 x 25.4 x 19.0 | Low Phase Noise | ||
OCXO3320AW | 8 to 100 | HCMOS, Sinewave | 5 | 3.3 | -40 to +85 | 16 x 15 x 7.5 | Low Power | ||
OCXO3307AW-10MHz-H-V | 10 | HCMOS | 10 | 3.3 | -40 to +85 | 20.5 x 15.3 x 9.5 | High Stability | ||
OCXO2020CF-100MHz-A-V | 100 | Sinewave | 100 | 5 | -40 to +70 | 20.5 x 20.5 x 10 | Standard | ||
DOCXO3627AW-100MHz-A-V | 100 | Sinewave | 0.2 | 5 | -20 to +70 | 35.4 x 26.7 x 15.8 | Ultra-stable | ||
DOCXO3627AW-20MHz-A-V | 20 | HCMOS | 0.05 | 3.3 | 0 to +50 | 35.4 x 26.7 x 15.8 | Ultra-stable | ||
DOCXO3627AW-100MHz-B-V | 20 | HCMOS | 0.05 | 3.3 | 0 to +50 | 35.4 x 26.7 x 15.8 | Ultra-stable | ||
OCXO3320AW_5V | 8 to 100 | HCMOS, TTL | 10 | 5 | -40 to +85 | 16 x 15 x 7.5 | Low Power | ||
OCXO2525BM-40MHz-A-V | 40 | HCMOS | 5 | 3.3 | 0 to +70 | 25.8 x 25.8 x 12.7 | Standard | ||
DOCXO2020AW_Sine | 5 to 100 | Sinewave | 0.1 to 2.0 | 3.3, 5 | -40 to +85 | 20.2 x 20.2 x 13.8 | High Stability | ||
DOCXO2020AW_HCMOS | 5 to 100 | HCMOS | 0.1 to 2.0 | 3.3, 5 | -40 to +85 | 20.2 x 20.2 x 13.8 | High Stability | ||
DOCXO3627BM-10MHz | 10 | HCMOS | 0.1 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO2020AW-100MHz-B-V | 100 | HCMOS | 0.5 | 3.3 | -40 to +80 | 20.2 x 20.2 x 13.8 | High Stability | ||
DOCXO3627BM-10MHz-421 | 10 | HCMOS | 0.3 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-221 | 10 | HCMOS | 0.1 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-321 | 10 | HCMOS | 0.2 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-621 | 10 | HCMOS | 0.5 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
OCXO2525C_Rev2-6-6-6-1-2-100MHz | 100 | Sinewave | 10 | 5 | -40 to +85 | 25.8 x 25.8 x 12.7 | Low Noise | ||
OCXO2525C_Rev2-6-6-7-1-2-120MHz | 120 | Sinewave | 10 | 5 | -40 to +85 | 25.8 x 25.8 x 12.7 | Low Noise | ||
DOCXO3627BM-10MHz-222 | 10 | HCMOS | 0.1 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-322 | 10 | HCMOS | 0.2 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-422 | 10 | HCMOS | 0.3 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-622 | 10 | HCMOS | 0.5 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-223 | 10 | HCMOS | 0.1 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-323 | 10 | HCMOS | 0.2 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-423 | 10 | HCMOS | 0.3 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-623 | 10 | HCMOS | 0.5 | 5 | -40 to +85 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-111 | 10 | HCMOS | 0.05 | 5 | -10 to +70 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-311 | 10 | HCMOS | 0.2 | 5 | -10 to +70 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-411 | 10 | HCMOS | 0.3 | 5 | -10 to +70 | 36 x 27 x 18 | Double Oven | ||
DOCXO2020AW-100MHz-C-V_Rev2 | 100 | HCMOS | 0.2 | 3.3 | -40 to +85 | 20.2 x 20.2 x 13.8 | High Stability | ||
DOCXO3627BM-10MHz-212 | 10 | HCMOS | 0.1 | 5 | -10 to +70 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-112 | 10 | HCMOS | 0.05 | 5 | -10 to +70 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-312 | 10 | HCMOS | 0.2 | 5 | -10 to +70 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-412 | 10 | HCMOS | 0.3 | 5 | -10 to +70 | 36 x 27 x 18 | Double Oven | ||
OCXO3312AW-100MHz-A-V | 100 | Sinewave | 100 | 5 | -55 to +85 | 16 x 15 x 9.5 | Low Power | ||
DOCXO2020AW-100MHz-D-V | 100 | HCMOS | 0.3 | 3.3 | -40 to +80 | 20.2 x 20.2 x 13.8 | High Stability | ||
DOCXO3627BM-10MHz-113 | 10 | HCMOS | 0.05 | 5 | -10 to +70 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-213 | 10 | HCMOS | 0.1 | 5 | -10 to +70 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-313 | 10 | HCMOS | 0.2 | 5 | -10 to +70 | 36 x 27 x 18 | Double Oven | ||
DOCXO3627BM-10MHz-413 | 10 | HCMOS | 0.3 | 5 | -10 to +70 | 36 x 27 x 18 | Double Oven | ||
OCXO3319AW-106.3742MHz-A-V | 106.3742 | Sinewave | 50 | 5 | 10 to +70 | 20.9 x 15.3 x 9.5 | Low Power | ||
OCXO2525BM-FD-10MHz_LVTTL | 10 | LVTTL | 3, 5, 10 | 3.3 | -40 to +85 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BM-FD-10MHz_LVTTL-2111 | 10 | LVTTL | 5 | 3.3 | -30 to +70 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BM-FD-10MHz_LVTTL-1111 | 10 | LVTTL | 3 | 3.3 | -30 to +70 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BM-FD-10MHz_LVTTL-3111 | 10 | LVTTL | 10 | 3.3 | -30 to +70 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BM-FD-10MHz_LVTTL-1211 | 10 | LVTTL | 3 | 3.3 | -40 to +85 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BM-FD-10MHz_LVTTL-2211 | 10 | LVTTL | 5 | 3.3 | -40 to +85 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BM-FD-10MHz_LVTTL-3211 | 10 | LVTTL | 10 | 3.3 | -40 to +85 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BM-FD-10MHz_LVTTL-1122 | 10 | LVTTL | 3 | 3.3 | -30 to +70 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BM-FD-10MHz_LVTTL-3122 | 10 | LVTTL | 10 | 3.3 | -30 to +70 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BM-FD-10MHz_LVTTL-2122 | 10 | LVTTL | 5 | 3.3 | -30 to +70 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BM-FD-10MHz_LVTTL-1222 | 10 | LVTTL | 3 | 3.3 | -40 to +85 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BM-FD-10MHz_LVTTL-2222 | 10 | LVTTL | 5 | 3.3 | -40 to +85 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO2525BFLN | 80 to 130 | Sinewave | 25 | 12 | -55 to +85 | 25.8 x 25.8 x 12.7 | Low Noise | ||
OCXO2526AXLG | 10 to 100 | Sinewave | 50 | 3.3, 5, 12 | -40 to +85 | 26.16 x 26.16 x 11.68 | Low G-Sensitivity | ||
OCXO2526AN | 48 to 1228.8 | Sinewave | 300 | 5, 12 | -40 to +85 | 25.8 x 25.8 x 10.3 | Low Noise | ||
OCXO2525AW-30.72MHz-A-V | 30.72 | HCMOS | 10 | 3.3 | -10 to +60 | 25.8 x 25.8 x 12.7 | High Stability | ||
OCXO1615C-SMD | 80 to 150 | Sinewave, HCMOS | 3 | 3.3, 5 | -40 to +85 | 16.0 x 15.2 x 9.5 | SMD | ||
DOCXO2020AW-10MHz-B-V | 10 | HCMOS | 0.5 | 3.3 | -40 to +85 | 20.2 x 20.2 x 13.8 | High Stability | ||
DOCXO2020AW-10MHz-A-V | 10 | Sinewave | 0.5 | 3.3 | -40 to +85 | 20.2 x 20.2 x 13.8 | High Stability | ||
OCXO2525BM-FD-10MHz_LVTTL-3222 | 10 | LVTTL | 10 | 3.3 | -40 to +85 | 25.4 x 25.4 x 12.7 | Standard | ||
OCXO3307AW-64MHz-A-V | 64 | Sinewave | 100 | 3.3 | -40 to +85 | 20.2 x 20.2 x 13.8 | Low Power | ||
OCXO2525AW-61.44MHz-A-V | 61.44 | HCMOS | 10 | 3.3 | -10 to +60 | 25.8 x 25.8 x 12.7 | High Stability | ||
OCXO3627AR-40.92MHz-A-V | 40.92 | CMOS | 10 | 5 | -20 to +70 | 36.0 x 27.1 x 15.0 | High Stability | ||
OCXO3307C-25MHz-A-V | 25 | HCMOS | 100 | 3.3 | -40 to +85 | 20.5 x 15.3 x 9.5 | High Stability | ||
OCXO2525S-100MHz-ULN-4 | 100 | Sinewave | 50 | 12 | -20 to +70 | 25.78 x 25.78 x 12.70 | Low Noise | ||
OCXO3307AW-10MHz-G-V | 10 | Sinewave | 3 | 5 | 0 to +50 | 20.5 x 15.3 x 9.5 | High Stability | ||
OCXO2020D11-10MHz-1-SZ | 10 | HCMOS | 10 | 5 | -40 to +70 | 20.6 x 20.6 x 11.0 | High Stability | ||
OCXO2525AM-10MHz-A-V | 10 | Sinewave | 50 | 5 | -55 to +70 | 25.8 x 25.8 x 13.0 | Extended Temperature | ||
OCXO3628L-37.5MHz-A-V | 37.5 | Sinewave | 100 | 5 | -20 to +70 | 36.1 x 27.2 x 16.0 | High Stability | ||
OCXO3627AM-10MHz-A-V | 10 | CMOS | 100 | 3.3 | -20 to +70 | 36.0 x 27.1 x 15.0 | High Stability | ||
OCXO3629L_series | 160 to 500 | Sinewave | 500 | 12 | -40 to +85 | 36.1 x 27.2 x 16.0 | VHF | ||
OCXO3628L-37.5MHz_series | 37.5 | Sinewave | 5 | 5, 12 | -55 to +85 | 36.1 x 27.2 x 16.0 | High Stability | ||
OCXO2525AM-100MHz-A-V | 100 | Sinewave | 100 | 12 | -40 to +85 | 25.8 x 25.8 x 10.0 | High Frequency | ||
OCXO3627D_series | 5 to 100 | Sinewave, CMOS, TTL | 20 | 3.3, 5, 12 | -40 to +85 | 36.4 x 27.4 x 13.0 | High Stability | ||
OCXO9700S-10MHz-A-V | 10 | Clipped Sinewave | 100 | 5 | -30 to +70 | 9.7 x 7.5 x 4.1 | Standard | ||
OCXO3627AN_series | 10 to 40 | Sinewave, HCMOS | 7.5 | 5, 12 | -40 to +85 | 36.1 x 27.2 x 16.0 | High Stability | ||
OCXO2522AN_series | 10 | Sinewave, HCMOS | 5 | 3.3, 5 | -40 to +85 | 25.4 x 25.4 x 14.0 | High Stability | ||
OCXO3307C-100MHz-D-V | 100 | Sinewave | 100 | 5 | -40 to +85 | 20.5 x 15.3 x 9.5 | Low Power | ||
DOCXO3627S-10MHz-A-V | 10 | HCMOS | 0.2 | 5 | -40 to +85 | 36.32 x 27.20 x 18.72 | High Stability | ||
DOCXO3627C-10MHz-A-V | 10 | HCMOS | 0.2 | 5 | -40 to +85 | 35.40 x 26.70 x 16.25 | Low Power | ||
OCXO3627AM-162MHz-A-V | 162 | Sinewave | 50 | 12 | -20 to +70 | 36.0 x 27.1 x 15.0 | High Frequency | ||
OCXO2525L-92.16MHz-A-V | 92.16 | Sinewave | 100 | 12 | -55 to +70 | 25.8 x 25.8 x 12.7 | Extended Temperature | ||
OCXO5050AM-285.714MHz-A-V | 285.714 | Sinewave | 100 | 5 | -20 to +70 | 50.8 x 50.8 x 25.0 | High Frequency | ||
OCXO2515AG-10MHz-A-V | 10 | CMOS | 20 | 3.3 | -20 to +70 | 25.0 x 15.0 x 9.6 | High Stability | ||
OCXO3627AM-100MHz-A-V | 100 | Sinewave | 50 | 12 | -40 to +85 | 36.0 x 27.1 x 15.0 | High Frequency | ||
OCXO3307C-100.8MHz-A-V | 100.8 | Sinewave | 30 | 5 | -40 to +85 | 21.6 x 15.3 x 9.5 | Low Power | ||
OCXO3312C-10MHz-F-V | 10 | Sinewave | 100 | 3.3 | -40 to +85 | 15.9 x 15.1 x 9.0 | Low Power | ||
OCXO3308C-80MHz-A-V | 80 | Sinewave | 50 | 3.3 | -40 to +85 | 21.51 x 19.00 x 8.80 | Low Power | ||
OCXO3308C-10MHz-A-V | 10 | HCMOS | 3 | 5 | -40 to +85 | 21.51 x 19.00 x 8.80 | Low Power | ||
OCXO2020C-10MHz-A-V | 10 | HCMOS | 3 | 5 | -40 to +85 | 20.2 x 20.2 x 14.1 | Low Power | ||
OCXO2525AN-10MHz-A-V | 10 | HCMOS | 10 | 5 | -20 to +70 | 25.8 x 25.8 x 12.7 | High Stability | ||
OCXO3307C-10MHz-F-V | 10 | Sinewave | 5 | 5 | -20 to +85 | 21.51 x 15.10 x 8.80 | Low Power | ||
OCXO4130AN-10MHz-A-V | 10 | Sinewave | 1 | 5 | -40 to +85 | 41.0 x 30.0 x 16.0 | High Performance | ||
OCXO2522C-65221-10MHz | 10 | HCMOS | 5 | 3.3 | -40 to +85 | 25.4 x 22.0 x 11.0 | High Stability | ||
OCXO2522C-65621-100MHz | 100 | HCMOS | 5 | 3.3 | -40 to +85 | 25.4 x 22.0 x 11.0 | High Stability | ||
OCXO3312C-10MHz-D-V | 10 | Sinewave | 100 | 3.3 | -40 to +85 | 16.0 x 15.3 x 9.5 | Low Power | ||
OCXO2020AM-38.4MHz-A-V | 38.4 | Sinewave | 300 | 5 | -55 to +70 | 20.4 x 20.4 x 10.7 | Extended Temperature | ||
OCXO3307C-10MHz-E-V | 10 | Sinewave | 100 | 5 | -40 to +85 | 21.5 x 15.3 x 9.5 | Low Power | ||
OCXO3312C-10MHz-C-V | 10 | HCMOS | 50 | 3.3 | -40 to +85 | 16.0 x 15.3 x 9.5 | Low Power | ||
OCXO3312C-40MHz-A-V | 40 | LVCMOS | 100 | 3.3 | -40 to +85 | 16.0 x 15.3 x 9.5 | Low Power | ||
OCXO3526Z-10MHz-A-V | 10 | Sinewave | 2 | 12 | -40 to +85 | 35.6 x 26.8 x 17.0 | High Stability | ||
OCXO1615C-73.728MHz-A-V | 73.728 | Sinewave | 100 | 5 | -40 to +85 | 16.0 x 15.3 x 9.5 | Low Power | ||
OCXO2020C-ET-10MHz-A-V | 10 | Sinewave | 5 | 5 | -55 to +85 | 20.2 x 20.2 x 10.3 | Extended Temperature | ||
OCXO2525P-100MHz-w-x-y | 100 | Sinewave | 50 | 5 | -40 to +85 | 25.8 x 25.8 x 12.7 | Low Noise | ||
OCXO2525L-100MHz-F-V | 100 | Sinewave | 200 | 12 | -40 to +70 | 25.8 x 25.8 x 12.7 | Low Noise | ||
OCXO2525L-100MHz-G-V | 100 | Sinewave | 200 | 12 | -40 to +70 | 25.8 x 25.8 x 12.7 | Sinewave | ||
OCXO5050Z-10MHz-C-V | 10 | Sinewave | 1 | 5 | -40 to +85 | 50.8 x 50.8 x 16.0 | Ultra Stable | ||
OCXO3307C-73.728MHz-A-V | 73.728 | Sinewave | 100 | 3.3 | -40 to +85 | 20.5 x 15.3 x 9.0 | Low Power | ||
OCXO2525L-100MHz-E-V | 100 | Sinewave | 20 | 12 | -20 to +70 | 25.8 x 25.8 x 12.7 | Low Noise | ||
OCXO5050Z-10MHz-B-V | 10 | Sinewave | 5 | 12 | -20 to +70 | 50.8 x 50.8 x 16.0 | High Stability | ||
OCXO3313C-100MHz-A-V | 100 | Sinewave | 50 | 5 | -40 to +85 | 16.0 x 15.3 x 9.5 | Low Power | ||
OCXO2522S-10MHz-A-V | 10 | Sinewave | 100 | 5 | -40 to +85 | 25.4 x 22.1 x 11.0 | Sinewave | ||
OCXO3312C-10MHz-B-V | 10 | Sinewave | 50 | 5 | -30 to +70 | 16.0 x 15.3 x 9.0 | Low Power | ||
OCXO2525D-133.25MHz-A | 133.25 | Sinewave | 200 | 12 | -40 to +75 | 26.16 x 26.16 x 11.68 | Low Noise | ||
OCXO3306C-100MHz-A-V | 100 | HCMOS | 30 | 5 | -20 to +70 | 21.51 x 15.10 x 8.00 | Low Power | ||
OCXO3307C-100MHz-C-V | 100 | Sinewave | 50 | 5 | -40 to +85 | 21.51 x 15.10 x 8.80 | Low Power | ||
OCXO3306C-16.8MHz-A-V | 16.8 | HCMOS | 50 | 3.3 | -40 to +85 | 21.8 x 15.1 x 7.5 | Low Power | ||
OCXO2525C-125MHz-A-V | 125 | Sinewave | 50 | 12 | 0 to +50 | 25.8 x 25.8 x 12.7 | High Stability | ||
OCXO3307C-ET-80MHz-A-V | 80 | Sinewave | 100 | 5 | -55 to +85 | 20.5 x 15.3 x 9.0 | Extended Temperature | ||
OCXO3307C-ET | 8 to 150 | Sinewave | 20 | 3.3, 5 | -60 to +85 | 21.6 x 15.3 x 9.5 | Extended Temperature | ||
OCXO2525AG-10MHz-A-V | 10 | Sinewave | 50 | 5 | -40 to +85 | 25.6 x 25.6 x 12.2 | High Stability | ||
OCXO3312C-16.8MHz-B-V | 16.8 | Sinewave | 50 | 3.3 | -30 to +70 | 15.9 x 15.1 x 9.0 | Low Power | ||
OCXO3312C-16.8MHz-A-V | 16.8 | HCMOS | 50 | 3.3 | -40 to +85 | 15.9 x 15.1 x 9.0 | Low Power | ||
OCXO2525D_series | 64.8 to 120 | Sinewave | 0.4 | 12 | -40 to +70 | 26.16 x 26.16 x 13.46 | Standard | ||
OCXO3307-10MHz-F-V | 10 | Sinewave | 0.1 | 5 | -10 to +60 | 35.40 x 26.70 x 16.25 | Ultra Stable | ||
OCXO3307-10MHz-G-V | 10 | Sinewave | 0.1 | 5 | -10 to +60 | 35.40 x 26.70 x 16.25 | Ultra Stable | ||
OCXO2020C-61.44MHz-A-V | 61.44 | Sinewave | 100 | 5 | -55 to +85 | 20.2 x 20.2 x 12.9 | Extended Temperature | ||
OCXO2020C-120MHz-A-V | 120 | Sinewave | 100 | 12 | -40 to +85 | 20.2 x 20.2 x 12.0 | Vibration Resistant | ||
OCXO2020C-120MHz-A-V | 120 | Sinewave | 100 | 12 | -40 to +85 | 20.2 x 20.2 x 12.0 | Vibration Resistant | ||
OCXO3307C-42.8MHz-B-V | 42.8 | HCMOS | 10 | 5 | -40 to +85 | 21.51 x 15.10 x 8.80 | Low Power | ||
OCXO3307C-100MHz-B-V | 100 | Sinewave | 50 | 5 | -30 to +70 | 21.51 x 15.10 x 8.80 | Low Power | ||
OCXO2525L-80MHz-A-V | 80 | Sinewave | 50 | 12 | -20 to +70 | 25.8 x 25.8 x 12.7 | High Stability | ||
OCXO2020C-78.6432MHz-A-V | 78.6342 | Sinewave | 20 | 5 | -45 to +70 | 20.2 x 20.2 x 12.0 | Low Power | ||
OCXO3307T-10MHz-A-F | 10 | Sinewave | 0.2 | 5 | -40 to +85 | 36.32 x 27.2 x 18.72 | Ultra Stable | ||
OCXO3307C-10MHz-D-V | 10 | HCMOS | 5 | 3.3 | -40 to +85 | 21.51 x 15.10 x 8.80 | Low Power | ||
OCXO2525S-10MHz-B-V | 10 | Sinewave | 5 | 5 | -30 to +70 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO5050L-100MHz-D-V | 100 | Sinewave | 100 | 12 | -40 to +85 | 50.0 x 50.0 x 30.0 | Low Noise | ||
OCXO2020S-10MHz-A-V | 10 | HCMOS | 50 | 5 | -40 to +85 | 20.6 x 20.6 x 11.0 | Standard | ||
OCXO2020S-10MHz-B-V | 10 | HCMOS | 50 | 5 | -40 to +85 | 20.6 x 20.6 x 11.0 | Standard | ||
OCXO3627S-10MHz-A | 10 | HCMOS | 3 | 5 | -40 to +85 | 36.32 x 27.18 x 12.70 | High Performance | ||
OCXO2020M-40MHz-A | 40 | Sinewave | 20 | 5 | -40 to +85 | 20.6 x 20.6 x 12.0 | High Performance | ||
OCXO3307C-20MHz-A-V | 20 | HCMOS | 50 | 5 | -40 to +85 | 21.51 x 15.10 x 9.00 | Low Power | ||
OCXO2525L-100MHz-C-A | 100 | Sinewave | 500 | 12 | -40 to +70 | 21.51 x 15.10 x 12.70 | Low Noise | ||
OCXO2525M12V-100MHz_Rev2 | 100 | Sinewave | 300 | 12 | -40 to +70 | 25.8 x 25.8 x 10.0 | Low Noise | ||
OCXO2020C-92.16MHz-A-V | 92.16 | Sinewave | 20 | 5 | -30 to +70 | 20.2 x 20.2 x 12.0 | High Performance | ||
OCXO2020D-25.6MHz-A-V | 25.6 | Sinewave | 50 | 5 | -45 to +85 | 20.0 x 20.0 x 10.0 | Hermetically Sealed | ||
OCXO3307C-10MHz-C-V | 10 | Sinewave | 3 | 5 | -40 to +85 | 20.9 x 15.3 x 9.5 | Low Power | ||
OCXO2020C-52MHz-A-V | 52 | Sinewave | 10 | 5 | -40 to +85 | 20.2 x 20.2 x 12.9 | High Performance | ||
OCXO2020C-104MHz-A-V | 104 | Sinewave | 10 | 5 | -40 to +85 | 20.2 x 20.2 x 12.9 | High Performance | ||
OCXO3307C-42.8MHz-A-V | 42.8 | HCMOS | 10 | 3.3 | -40 to +85 | 20.5 x 15.1 x 9.3 | Low Power | ||
OCXO3307LP-20MHz-A-V | 20 | HCMOS | 50 | 3.3 | -40 to +85 | 21.51 x 15.10 x 8.80 | Low Power | ||
OCXO3307LP-10MHz-A-V | 10 | HCMOS | 10 | 3.3 | -40 to +85 | 21.51 x 15.10 x 8.00 | Low Power | ||
OCXO3307LP-42.8MHz-A-V | 42.8 | HCMOS | 30 | 3.3 | -40 to +85 | 21.51 x 15.10 x 8.00 | Low Power | ||
OCXO3311C-100MHz-A-V-ET | 100 | Sinewave | 100 | 5 | -55 to +85 | 21.85 x 15.10 x 10.00 | Extended Temperature | ||
DOCXO3627S-10MHz-B-V | 10 | Sinewave | 0.2 | 5 | -40 to +85 | 36.32 x 27.20 x 18.72 | Ultra Stable | ||
OCXO2525L-100MHz-B-V | 100 | Sinewave | 50 | 12 | -30 to +70 | 25.8 x 25.8 x 12.7 | High Stability | ||
OCXO3627M-26MHz-A-V | 26 | Sinewave | 3 | 5 | -20 to +70 | 36.0 x 27.1 x 13.0 | High Stability | ||
OCXO2020C-117MHz-A-V | 117 | Sinewave | 20 | 5 | -40 to +70 | 20.2 x 20.2 x 12.0 | High Stability | ||
OCXO2525L-10MHz-A-V | 10 | Sinewave | 10 | 12 | -40 to +70 | 25.8 x 25.8 x 12.7 | High Stability | ||
OCXO3307-10MHz-E-V | 10 | Sinewave | 0.1 | 12 | 0 to +80 | 35.40 x 26.70 x 16.25 | High Stability | ||
OCXO3307C-10MHz-A-V | 10 | Sinewave | 100 | 5 | -40 to +85 | 21.51 x 15.10 x 8.80 | Low Power | ||
OCXO3307C-100MHz-A-V | 100 | Sinewave | 100 | 5 | -40 to +85 | 21.51 x 15.10 x 8.80 | Low Power | ||
OCXO5051L | 300 to 1500 | Sinewave | 100 | 12 | -55 to +85 | 50.0 x 50.0 x 21.0 | Extended Temperature | ||
OCXO5050L | 200 | Sinewave | 100 | 12 | -40 to +85 | 50.0 x 50.0 x 21.0 | Low Noise | ||
OCXO5151L | 80 to 125 | Sinewave | 200 | 12 | -10 to +60 | 51.0 x 51.0 x 19.0 | Low Noise | ||
OCXO2020C | 5 to 150 | Sinewave, HCMOS | 10 | 5 | -40 to +85 | 20.2 x 20.2 x 12.0 | High Stability | ||
OCXO3307C-10MHz-B-V | 10 | Sinewave | 5 | 5 | -40 to +70 | 21.51 x 15.10 x 8.80 | Low Power | ||
OCXO2215L | 10 to 125 | Sinewave, HCMOS | 10 | 3.3, 5, 12 | -40 to +85 | 22.7 x 15.1 x 11.0 | High Stability | ||
OCXO2216L | 10 to 125 | Sinewave | 10 | 3.3, 5 | -40 to +85 | 22.7 x 15.1 x 11.0 | High Stability | ||
OCXO2727L | 5 to 40 | HCMOS | 200 | 3.3, 5 | -55 to +85 | 27.8 x 27.8 x 15.5 | Extended Temperature | ||
OCXO2525BM-FD-10MHz_Sine | 10 | Sinewave | 3 | 5 | -40 to +85 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO2525BM-FD-10MHz_Sine-2111 | 10 | Sinewave | 5 | 5 | -30 to +70 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO2525BM-FD-10MHz_Sine-1111 | 10 | Sinewave | 3 | 5 | -30 to +70 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO2728L | 5 to 150 | Sinewave | 200 | 5 | -55 to +85 | 27.8 x 27.8 x 15.5 | Extended Temperature | ||
OCXO2527L | 80 to 125 | Sinewave | 25 | 12 | -40 to +85 | 25.8 x 25.8 x 12.7 | VHF | ||
OCXO5440L | 10 | Sinewave | 25 | 3.3 | -55 to +85 | 54.0 x 40.5 x 19.0 | Extended Temperature | ||
OCXO5441L | 80 to 130 | Sinewave | 25 | 5 | -55 to +85 | 54.0 x 40.5 x 19.0 | Extended Temperature | ||
OCXO2021L | 10 to 125 | Sinewave | 10 | 3.3 | -40 to +85 | 20.5 x 20.5 x 12.0 | High Stability | ||
OCXO2022L | 10 to 20 | Sinewave | 25 | 5 | -55 to +85 | 20.5 x 20.5 x 12.0 | Extended Temperature | ||
OCXO2023L | 80 to 125 | Sinewave | 25 | 12 | -55 to +85 | 20.5 x 20.5 x 12.0 | Extended Temperature | ||
OCXO3627L | 5 to 125 | HCMOS | 10 | 5 | -40 to +85 | 36.1 x 27.2 x 16.0 | High Stability | ||
OCXO3628L | 5 to 125 | Sinewave | 10 | 5 | -40 to +85 | 36.1 x 27.2 x 16.0 | High Stability | ||
OCXO2525L | 5 to 40 | HCMOS | 10 | 3.3, 5 | -40 to +85 | 25.8 x 25.8 x 12.7 | High Stability | ||
OCXO2526L | 5 to 150 | Sinewave | 10 | 5 | -40 to +85 | 25.8 x 25.8 x 12.7 | High Stability | ||
OCXO2525C | 5 to 150 | Sinewave | 3 | 3.3 | -40 to +85 | 25.80 x 25.80 x 13.35 | High Stability | ||
OCXO2522L | 10 to 125 | HCMOS | 10 | 3.3, 5, 12 | -55 to +85 | 25.6 x 22.4 x 14.0 | Extended Temperature | ||
OCXO2523L | 10 to 125 | Sinewave | 10 | 3.3 | -55 to +85 | 25.6 x 22.4 x 14.0 | Extended Temperature | ||
OCXO2013L | 10 to 125 | HCMOS | 10 | 3.3 | -40 to +85 | 20.7 x 13.1 x 8.5 | High Stability | ||
OCXO2014L | 10 to 125 | Sinewave | 10 | 3.3 | -40 to +85 | 20.7 x 13.1 x 8.5 | High Stability | ||
OCXO2020L | 10 to 125 | HCMOS | 10 | 3.3 | -40 to +85 | 20.5 x 20.5 x 12.0 | High Stability | ||
OCXO3309C-20MHz-A-V | 20 | HCMOS | 20 | 5 | -40 to +85 | 15.9 x 15.1 x 9.0 | Low Power | ||
OCXO2020C-81.92MHz-A-V | 81.92 | HCMOS | 30 | 5 | -30 to +70 | 20.2 x 20.2 x 12.0 | VHF | ||
OCXO3309C-150MHz-A-V | 150 | Sinewave | 300 | 5 | -10 to +60 | 15.9 x 15.1 x 9.0 | VHF | ||
OCXO2525BM-FD-10MHz_Sine-1211 | 10 | Sinewave | 3 | 5 | -40 to +85 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO2525BM-FD-10MHz_Sine-2211 | 10 | Sinewave | 5 | 5 | -40 to +85 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO2525D-100MHz-A-V | 100 | Sinewave | 100 | 12 | -40 to +70 | 26.16 x 26.16 x 11.68 | VHF | ||
OCXO3309C-10MHz-A-V | 10 | Sinewave | 50 | 5 | -30 to +70 | 15.9 x 15.1 x 9.0 | Low Power | ||
OCXO2525L-100MHz-A-V | 100 | Sinewave | 50 | 12 | -20 to +70 | 25.8 x 25.8 x 12.7 | Low Noise | ||
OCXO3315-10.0MHz-LN_Rev2 | 10 | Sinewave | 10 | 5 | -40 to +85 | 20.2 x 20.2 x 12.0 | Low Noise | ||
OCXO3627MC-40MHz-A-V | 40 | Sinewave | 2 | 3.3 | -40 to +85 | 36.4 x 27.4 x 12.7 | High Stability | ||
OCXO2020MX-10MHz-A-V | 10 | Sinewave | 3 | 5 | -40 to +85 | 20.20 x 20.20 x 14.03 | High Stability | ||
OCXO2522MC-100MHz-A-V_Rev2 | 100 | Sinewave | 50 | 5 | -40 to +85 | 25.4 x 22.0 x 10.8 | VHF | ||
OCXO2020MX-88.052500MHz-A-V | 88.0525 | Sinewave | 200 | 12 | -20 to +70 | 20.2 x 20.2 x 12.0 | VHF | ||
OCXO3627T-12.8MHz-A-V | 12.8 | HCMOS | 10 | 12 | -40 to +85 | 36.32 x 27.18 x 12.70 | High Stability | ||
OCXO5050M-LN-10MHz | 10 | Sinewave | 1 | 12 | -40 to +70 | 50.8 x 50.8 x 12.7 | Low Noise | ||
OCXO2525BM-FD-10MHz_Sine-3211 | 10 | Sinewave | 10 | 5 | -40 to +85 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO2525BM-FD-10MHz_Sine-3111 | 10 | Sinewave | 10 | 5 | -30 to +70 | 25.78 x 25.78 x 12.70 | High Stability | ||
DOCXO3627M-LN-10MHz | 10 | Sinewave | 0.5 | 12 | -40 to +70 | 36.1 x 27.2 x 19.0 | High Stability | ||
OCXO2525N-10MHz-A | 10 | HCMOS | 100 | 12 | -40 to +85 | 25.4 x 25.4 x 12.5 | Standard | ||
OCXO2525BM-FD-10MHz_Sine-1122 | 10 | Sinewave | 3 | 5 | -30 to +70 | 25.4 x 25.4 x 12.7 | High Stability | ||
OCXO3627N-20MHz-A-V | 20 | Sinewave | 20 | 5 | -30 to +70 | 36.0 x 27.1 x 13.0 | High Stability | ||
OCXO2020NF-10.000MHz-LP | 10 | Sinewave | 20 | 5 | -20 to +70 | 20.2 x 20.2 x 10.0 | High Stability | ||
OCXO2020NF-10.000MHz | 10 | Sinewave | 20 | 5 | -40 to +85 | 20.2 x 20.2 x 10.0 | High Stability | ||
OCXO2525TH-10Mhz-A-V | 10 | CMOS | 5 | 3.3 | -40 to +85 | 25.4 x 25.4 x 12.7 | High Stability | ||
OCXO2525T-10MHz-A | 10 | LVTTL | 5 | 3.3 | -40 to +75 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO2525T-10MHz-B | 10 | LVTTL | 5 | 3.3 | -40 to +75 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO2012T-40MHz-A | 40 | LVCMOS | 5 | 3.3 | -40 to +85 | 20.3 x 12.7 x 11.0 | Standard | ||
OCXO2525BM-FD-10MHz_Sine-3122 | 10 | Sinewave | 10 | 5 | -30 to +70 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO2525BM-FD-10MHz_Sine-2122 | 10 | Sinewave | 5 | 5 | -30 to +70 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO3306AW-10MHz-A-V | 10 | HCMOS | 10 | 5 | 0 to +70 | 21.6 x 15.3 x 7.5 | Low Power | ||
OCXO2525BM-FD-10MHz_Sine-1222 | 10 | Sinewave | 3 | 5 | -40 to +85 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO2525BM-FD-10MHz_Sine-2222 | 10 | Sinewave | 5 | 5 | -40 to +85 | 25.78 x 25.78 x 12.70 | High Stability | ||
OCXO3320AW-10MHz-3-2-4-2-1 | 10 | HCMOS | 10 | 5 | 0 to +70 | 16.0 x 15.3 x 7.5 | Low Power | ||
OCXO2525BM-FD-10MHz_Sine-3222 | 10 | Sinewave | 10 | 5 | -40 to +85 | 25.4 x 25.4 x 12.7 | High Stability | ||
OCXO3627BM-FD5-10MHz_LVTTL | 10 | Rectangular | 10 | 5 | -40 to +85 | 36.30 x 27.18 x 12.70 | Fast Delivery | ||
OCXO3318AW-100MHz-2-6-5-7-2-2 | 100 | Sinewave | 30 | 5 | -40 to +85 | 16.00 x 15.24 x 11.60 | Low Power | ||
OCXO2014BF-10MHz-B-V | 10 | Sinewave | 100 | 5 | -40 to +85 | 20.7 x 13.1 x 8.5 | Sinewave | ||
OCXO2014BF-10MHz-A-V | 10 | Sinewave | 50 | 5 | -40 to +85 | 20.7 x 13.1 x 8.5 | Sinewave | ||
OCXO3321AW02 | 8 to 150 | Sinewave, HCMOS | 2 | 3.3, 5 | -40 to +85 | 21.6 x 15.3 x 11.6 | Low Power | ||
OCXO3322AW02 | 30 to 300 | Sinewave, HCMOS | 10 | 3.3, 5 | -40 to +85 | 21.6 x 15.3 x 10.5 | Low Power | ||
DOCXO3628AW-100MHz-A-V | 100 | Sinewave | 0.3 | 5 | -30 to +70 | 35.4 x 26.7 x 15.8 | Low Power | ||
DOCXO5151AN-SPI-10MHz-A-V | 10 | Sinewave | 0.1 | 5 | -40 to +85 | 51.0 x 51.0 x 19.0 | Double Oven | ||
DOCXO5151AN01-HS | 4.096 to 10 | Sinewave | 0.05 | 12 | -40 to +70 | 51.0 x 51.0 x 38.0 | Double Oven | ||
OCXO3627CO-10MHz-A-V | 10 | CMOS | 10 | 5 | -20 to +70 | 36.0 x 27.0 x 12.7 | High Performance | ||
OCXO3321AW02-100MHz-657221_Rev2 | 100 | Sinewave | 10 | 5 | -40 to +85 | 20.5 x 15.3 x 11.6 | Low Power | ||
OCXO2525CP-10MHz-A-V | 10 | HCMOS | ±20ppb | 5 | -40 to +85 | 25.4x25.4x12.2mm | OCXO | ||
OCXO9700BM-30.72MHz-A-V | 30.72 | HCMOS | 20 | 3.3 | -40 to +85 | 9.7 x 7.5 x 4.1 | 30.72MHz OCXO | ||
OCXO9700BM-30.72MHz-A-V | 30.72 | HCMOS | 20 | 3.3 | -40 to +85 | 9.7 x 7.5 x 4.1 | 30.72MHz OCXO | ||
OCXO2525BM-40MHz-B-V | 40 | Sinewave | 10 | 12 | -30 to +70 | 25.7 x 25.7 x 12.7 | 40MHz OCXO | ||
OCXO2525BM-40MHz-C-V | 40 | Sinewave | 100 | 5 | -30 to +70 | 25.7 x 25.7 x 12.7 | 40MHz OCXO | ||
DOCXO3627AW-10MHz-B-V | 10 | Sinewave | 0.05 | 5 | -40 to +85 | 35.4 x 26.7 x 15.8 | Ultra-stable double-oven OCXO |
